4' X8' LAGUNA SMARTCUT PLASMA CUTTER

Flashcut CNC Control with CAD/CAM Software
24-inch Control screen
X, Y helical rack and pinion, Z ball screw
Drive system Nema 32 (with Servo option)
GH20 Hiwin Bearing cards
Welded Steel Frame (No Aluminum Extrusion or Low Cost Bolt Together Tables)
Boss mount with Breakaway sensing Torch Holder
Laser Precision Pointer
7 Guage Mild Steel Slats
Z Clearance 8 inches
Automatic Lead in on Restart
THC (Torch Height Control)
Move to Point in Viewport
Progress Meter • Rip Cutting
Workpiece Alignment
Smart Touch Off Software Feature

Table:
Length: 48″
Width: 96″

Travel:
X-Axis: 49″
Y-Axis: 97″
Z-Axis: 08″ ?
Rapid Traverse Rates: 393 Inch Per Minute

General:
Power: 200-600V / 3-Phase
Overall Dimensions: 138″ x 92″ x 60″ High
Weight: 2000 lbs. approx.
