WATON MODEL ECO-4L PET STRETCH BLOW MOLDING MACHINE MFG 2021
ConditionUsed
1 available
2021 WATON ECO-4L Blow Molding Machine - lightly used, produces diverse bottles up to 2L, 4500 BPH capacity. Includes molds, leak tester, bagger, accumulator.
No. of Cavity 4 cavities
Cavity Center Distance 114.3(mm)
Max.capacity 2000 ml
Preform neck (inner dia.) 18~38(mm)
Preform height(max) 130(mm)
Bottle diameter(max) 105(mm)
Bottle height(max) 330(mm)
Heating ovens 4 (unit)
Infrared lamps 32 (pcs)
Consumption power 32 (kw)
Rated power 66 (kw)
Theory production（based on 500ml bottle） 4500 BPH
208 VOLT 3 PHASE
MOLDS -60 ML ,120 ML ,750 ML BOTTLES
FIVE HEAD LEAK TESTER
BOTTLE BAGGER
ACCUMULATOR
It can produce all kinds of bottles up to 2L, including food
packaging bottles, edible oil bottles, soda and mineral water bottles, fruit juice
bottles, wine bottles, cosmetics bottles and so on
