24"W x 48" Work envelope, 24" dia shuttling Rotary Tables, Automated Nozzles, Load/Unload station, Media system with clarifier
Main rotary table with two (2) 24" diam satellite stations to provide continuous work flow.
Satellite tables are servo driven to coordinate with nozzle traverse
Roof mounted, 2-axis nozzle manipulator to traverse the height and width of the blade.
Integral media reclaim and recovery system including vibratory classifier for size classification of peening media
All parts peened completely automatically
Process monitoring components including vibratory classifier and closed-loop pressure feedback system – to provide consistency of peening results
Pressure blast style media propulsion system with eight (8) nozzles.
User-friendly Allen Bradley HMI
